Distribution Box

EWJ DB Metal Distribution Box Junction Box

Engineered with precision and designed to meet the most stringent requirements, our metal boxes are the ultimate choice for businesses seeking durability, functionality, and versatility.

Request a Quote

Metal Boxes: Tailored Solutions for Diverse Industrial and Commercial Needs

1. Customization Ability
One of the great advantages of our metal boxes is that we offer a wide range of customization options, customizing metal boxes to your exact specifications.
The size, color, and style are all up to you.
2. We are a factory
As a leading metal box manufacturer and supplier, we have the unique advantage of being a source factory. By eliminating the middleman and working directly with our customers, we can offer unbeatable prices without sacrificing quality.
Choosing our factory-direct metal boxes, you can save significant costs, shorten production cycles, and enjoy the security of working directly with the manufacturer.
3. High-quality materials
We offer two high-quality metal box material options: iron and stainless steel.
4. IP65 waterproof rating
Our metal boxes are ideal for outdoor applications such as street lighting, traffic lights, and outdoor electrical installations, as well as indoor applications in wet environments such as bathrooms, kitchens, and laundries.

Technical Specifications

Name	Metal box
Protection grade	IP65
Surface Treatment	Powder technology
Brand	Guozhen
Model	EWJ
External dimensions	Custom Size
Material	Iron/Stainless steel
Package	Carton

Product Size

Model	H(mm)	W(mm)	D(mm)
ME202015	200	200	150
ME252015	250	200	150
ME302015	300	200	150
ME302515	300	250	150
ME303015	300	300	150
ME303020	300	300	200
ME403020	400	300	200
ME404020	400	400	200
ME504020	500	400	200
ME504025	500	400	250
ME505020	500	500	200
ME604020	600	400	200
ME605020	600	500	200
ME606020	600	600	200
ME705020	700	500	200
ME705025	700	500	250
ME705030	700	500	300
ME706025	700	600	250
ME806020	800	600	200
ME806025	800	600	250
ME808020	800	800	200
ME808025	800	800	250
ME1006025	1000	600	250
ME1006030	1000	600	300
ME1008025	1000	800	250
ME1008030	1000	800	300
ME1208025	1200	800	250
ME1208030	1200	800	300
ME12010030	1200	1000	300
